How to use relay switch in proteus ISIS

Embedded systems basics: How to use relay switch in proteus ISIS? Embedded systems step by step video guide -using PROTEUS ISIS professional and Arduino IDE software Here i am going to show you how to relay switch working in proteus isis. COMPONENTS: 1.LED light 2.Relay switch 3.lamp 4.Resistor 5.battery
Relay:
Relay is used to switch from lowcurrent to high current.
Mechanically controlled electrically activated switch.
